Brand
Milesight
Manufacturer part number
MS-S0224-GL
Warranty?
?
24 months
EAN
0708747440461
Milesight Industrial PoE Switch 400W
In stock
?
19% 178.87 €
145.20 €
19% 178.87 €
145.20 €
Warranty
Detailed description
Unmanaged PoE switch can provide both 10/100M Ethernet data and Power over network cable. It can be used as Ethernet Power Sourcing Equipment, It can automatically detect and identify whether connected devices such as IP camera comply with standard IEEE PoE 802.3af, 802.3at and supply power for them. 10/100M unmanaged PoE switch easier the deployment of wireless AP, IP camera and IP-based network equipment.
The PoE Priority function will protect the switch when it is overloaded. If all device's consumption is higher than specified, switch ports will be sorted by priority, Port1, Port2, Port3 etc. Then the power supply of the lowest priority will be turned off. You can estimate the working status of each port on front panel LED.
Please use 48V power supply, the switch will be damaged if use mismatched power supply. Please input AC 100-240V / 50Hz for internal power supply switch.
Features:
- Comply to IEEE802.3, IEEE802.3u, IEEE802.3af, IEEE802.3at
- 10/100M self adaptive, down link port support PoE
- All the ports support Auto MDI/MDIX
- Each port support power up to 15.4W (IEEE802.3af) or 30W (IEEE802.3at)
- Compatible with powered device applied to IEEE802.3af/at
- Support IEEE802.3x Full Duplex flow control and Duplex backpressure flow control function
- Automatic MAC address learning and aging
- High performance full load power configuration
- LED indicator monitor working status and help fault detection
Compare with similar products
| Ethernet Ports | ||||
| 24 x 100 Mbps, 2 x 1 Gbps | 6 x 100 Mbps | 8 x 100 Mbps, 2 x 1 Gbps | 16 x 100 Mbps, 2 x 1 Gbps | |
| PoE Out Ports | ||||
| 24 x 802.3af (PoE), 802.3at (PoE+) | 4 x 802.3af (PoE), 802.3at (PoE+) | 8 x 802.3af (PoE), 802.3at (PoE+) | 16 x 802.3af (PoE), 802.3at (PoE+) | |
| Max Power Consumption | ||||
| 400 W | 65 W | 120 W | 200 W | |
| Weight | ||||
| 2.2 kg | 0.5 kg | 0.7 kg | 1.5 kg | |
| Dimensions | ||||
| 330 x 204 x 44 mm | 142 x 115 x 40 mm | 195 x 130 x 40 mm | 271 x 181 x 44 mm | |
| Mounting Method | ||||
| RackMount, Wall Mount, Tabletop | Wall Mount, Tabletop | Wall Mount, Tabletop | RackMount, Wall Mount, Tabletop | |
| Ingress Protection Code | ||||
| IP30 | IP30 | IP30 | IP30 | |
| Ethernet Ports | 24 x 100 Mbps, 2 x 1 Gbps | 6 x 100 Mbps | 8 x 100 Mbps, 2 x 1 Gbps | 16 x 100 Mbps, 2 x 1 Gbps |
| PoE Out Ports | 24 x 802.3af (PoE), 802.3at (PoE+) | 4 x 802.3af (PoE), 802.3at (PoE+) | 8 x 802.3af (PoE), 802.3at (PoE+) | 16 x 802.3af (PoE), 802.3at (PoE+) |
| Max Power Consumption | 400 W | 65 W | 120 W | 200 W |
| Weight | 2.2 kg | 0.5 kg | 0.7 kg | 1.5 kg |
| Dimensions | 330 x 204 x 44 mm | 142 x 115 x 40 mm | 195 x 130 x 40 mm | 271 x 181 x 44 mm |
| Mounting Method | RackMount, Wall Mount, Tabletop | Wall Mount, Tabletop | Wall Mount, Tabletop | RackMount, Wall Mount, Tabletop |
| Ingress Protection Code | IP30 | IP30 | IP30 | IP30 |
