Ubiquiti airMAX PrismStation Horn 60°

Ubiquiti Elite Distributor
In stock
?
64.77
In stock
?
64.77

Brand

Ubiquiti

Manufacturer part number

Horn-5-60

Warranty
?

12 months

EAN

0817882020077

Detailed description

5 GHz Beamwidth Horn antenna with 60° precise radiation angles for specific beam shaping.

The airMAX PrismStation Horn 5 60° is an advanced directional horn antenna designed by Ubiquiti Networks, tailored to enhance and extend the capabilities of the airMAX PrismStation series. This device stands out in the wireless networking industry for its precision in beam shaping and exceptional interference mitigation, specifically engineered for both point-to-point (PtP) and point-to-multipoint (PtMP) configurations within the 5 GHz frequency spectrum. The Horn-5-60 is crafted to provide a perfect balance between wide coverage and focused signal strength, making it an essential component for network operators seeking to optimize their wireless infrastructure for high efficiency and reliability.
Compatible with airFiber, LTU and airMAX radios.
Integration with the PrismStation series is straightforward, thanks to the antenna's twist-lock mechanism, which ensures a secure and simple connection without the need for specialized tools or extensive installation procedures. This design not only facilitates rapid deployment and system scalability but also allows network operators to easily swap or upgrade antenna components as network requirements evolve. Moreover, the Horn-5-60 is also designed with compatibility in mind, seamlessly working with other Ubiquiti airMAX or LTU devices that support the same frequency band and connection interface. This interoperability allows for the creation of highly customized network deployments, catering to the specific coverage and performance needs of each installation.
Central to its design is a 60° beamwidth antenna that offers a unique combination of wide-area coverage and targeted signal concentration. This attribute allows the antenna to effectively distribute wireless signals across a broad area while maintaining the intensity and integrity of the signal, significantly enhancing network performance in diverse environments. The wide beamwidth is particularly beneficial in PtMP applications, where it can serve multiple client devices without sacrificing signal quality, thereby optimizing the use of the wireless spectrum and reducing the need for additional hardware. Also, 60° and 90° versions have naturally attenuated side lobes and extremely low back radiation. They offer the best front-to-back ratio in the industry and the lowest side lobe radiation. Asymmetrical horn antennas are ideal for cluster sector installations with high co-location requirements.
A distinguishing feature of the Horn-5-60 is its unparalleled RF isolation capabilities. The horn antenna design inherently minimizes the reception of off-axis signals, which are a common source of interference and noise in crowded RF environments. This reduction in signal interference is critical for maintaining a clean and clear communication channel, ensuring high-quality wireless connectivity even in areas with high levels of RF noise. Such performance is indispensable for deploying robust wireless networks in urban settings, industrial sites, and other locations where multiple wireless devices operate simultaneously.
Built to withstand the challenges of outdoor deployment, the Horn-5-60 features a rugged, weather-resistant construction. Its materials are selected for durability and resilience, ensuring that the antenna continues to perform optimally even in adverse weather conditions, including heavy rain, high winds, and extreme temperature variations. Such robustness is vital for maintaining the reliability and longevity of outdoor wireless networks, where equipment must endure constant exposure to the elements.

Compare with similar products


Wireless Antenna Frequency Range & Gain
5.15 - 5.85 (GHz) 16 (dBi)
5.15 - 5.85 (GHz) 19 (dBi)
5.15 - 5.85 (GHz) 15.5 (dBi)
5.15 - 5.85 (GHz) 13 (dBi)
5.15 - 6.875 (GHz) 19.5 (dBi)
Antenna beamwidth
60 ° Vertical, 60 ° Horizontal
30 ° Vertical, 30 ° Horizontal
45 ° Vertical, 45 ° Horizontal
90 ° Vertical, 90 ° Horizontal
30°
Polarization
Dual Linear
Dual Linear
Dual Linear
Dual Linear
Dual Linear
Dimensions
161.6 x 173.3 x 170.9 mm
Ø221.4 x 184.2 mm
Ø175 x 96 mm
152.1 x 186.8 x 113.2 mm
282 x 224 x 380 mm
Weight
0.72 kg
1.1 kg
1.34 kg
0.92 kg
3.93 kg

Wireless Antenna Frequency Range & Gain 5.15 - 5.85 (GHz) 16 (dBi)
5.15 - 5.85 (GHz) 19 (dBi)
5.15 - 5.85 (GHz) 15.5 (dBi)
5.15 - 5.85 (GHz) 13 (dBi)
5.15 - 6.875 (GHz) 19.5 (dBi)
Antenna beamwidth60 ° Vertical, 60 ° Horizontal
30 ° Vertical, 30 ° Horizontal
45 ° Vertical, 45 ° Horizontal
90 ° Vertical, 90 ° Horizontal
30°
PolarizationDual Linear
Dual Linear
Dual Linear
Dual Linear
Dual Linear
Dimensions 161.6 x 173.3 x 170.9 mm
Ø221.4 x 184.2 mm
Ø175 x 96 mm
152.1 x 186.8 x 113.2 mm
282 x 224 x 380 mm
Weight0.72 kg
1.1 kg
1.34 kg
0.92 kg
3.93 kg
