Reyee Wi-Fi 6 Ceiling Access Point

in stock

147.87 €

in stock

147.87 €

Get special price

Brand

Ruijie

Manufacturer part number

RG-RAP2260(G)

Warranty

36 months

EAN

6971693271838

Detailed description

Dual-Radio Performance, Gigabit Speed Wi-Fi Solution

Experience robust and secure networking with Reyee Access Point. It comes fully equipped with advanced security protocols, such as WPA2-PSK, WPA3-SAE and 802.1x authentication, as well as AES, TKIP and WEP encryption. Furthermore, RG-RAP2260(G) access point is fitted with powerful processor and beamforming technology for faster and more reliable performance.

Better Multi-User Experience in High-Density Scenarios

Performance upgraded, support client connections over 500.

With RG-RAP2260(G) you can easily build an ultra-high performance network in high density environment and connect up to 500 users. This dual-band access point features maximum throughput 2.97 Gbps. RG-RAP2260(G) operates in two bands with support for 2x2 MIMO technology at both 2.4 GHz and 5GHz. Thanks to the Reyee Mesh you can easily add extra outdoor Wi-Fi devices.

One Click to Optimize, Get Better Wi-Fi Experience

The WIO (Wi-Fi Intelligent Optimization) technology allows you to optimize wireless network by one click.

Easily Install Extra AP with Reyee Mesh

Layer 3 Roaming, Smooth Transition

Roam smoothly between Layer 3 networks with non-interruption

Easily Set Up Your Wi-Fi Network in 3 Minutes

With SON (Self-organizing Network) technology, easily set up a whole Wi-Fi network by Ruijie Cloud APP.

The RG-RAP2260(G) can be mounted on the ceiling or a wall, the mounting brackets are included. Thanks to the free Cloud Management you will be able to monitor and manage your device remotely, as well as use the wireless intelligent optimization and cloud portal authentication. Meanwhile, with SON (Self-organizing Network) technology, you can easily set up a whole Wi-Fi network by Ruijie Cloud APP.

/images/catalogue/description/1666/p7_01-651bcc1e9b096-1400x800.jpg

Compare with similar products

	RG-RAP2260(G)	RG-RAP73HD	RG-RAP2200(E)	RG-RAP2266
Wireless Standard

802.11ax, Wi-Fi 6	802.11be, Wi-Fi 7	802.11ac Wave2, Wi-Fi 5	802.11ax, Wi-Fi 6	802.11ax, Wi-Fi 6
MIMO

2.4GHz 2x2, 5GHz 2x2	2.4GHz 4x4, 5GHz 4x4, 6GHz 4x4	2.4GHz 2x2, 5GHz 2x2	2.4GHz 2x2, 5GHz 2x2	2.4GHz 4x4, 5GHz 4x4
2.4GHz Radio Rate

573 Mbps	1.378 Gbps	400 Mbps	573 Mbps	800 Mbps
5GHz Radio Rate

1.7 Gbps	5.76 Gbps	867 Mbps	2.4 Gbps	3.2 Gbps
6GHz Radio Rate

	11.52 Gbps
Wireless Antenna Frequency Range & Gain

2.4 - 2.4835 (GHz) 3 (dBi), 5.150 - 5.850 (GHz) 3 (dBi)	2.4 - 2.483 (GHz) 4 (dBi), 5.15 - 5.725 (GHz) 6 (dBi), 5.925 - 6.425 (GHz) 6 (dBi)	2.4 - 2.4835 (GHz) 2 (dBi), 5.150 - 5.850 (GHz) 2 (dBi)	2.4 - 2.483 (GHz) 3.53 (dBi), 5.15 - 5.85 (GHz) 5.15 (dBi)	2.4 - 2.4835 (GHz) 3 (dBi), 5.150 - 5.850 (GHz) 3 (dBi)
Ethernet Ports

2 x 1 Gbps	1 x 1 Gbps, 1 x 10 Gbps	2 x 1 Gbps	1 x 1 Gbps	1 x 1 Gbps, 1 x 2.5 Gbps
SFP Ports

	1 x 10G SFP+
Max Power Consumption

15.3 W	60 W	13 W	18 W	25.4 W
Max Client Capacity

512	1500	110	512	512
Recommended client capacity

100	250	40	110	120

	RG-RAP2260(G)	RG-RAP73HD	RG-RAP2200(E)	RG-RAP2266	RG-RAP2260(E)
Wireless Standard	802.11ax, Wi-Fi 6	802.11be, Wi-Fi 7	802.11ac Wave2, Wi-Fi 5	802.11ax, Wi-Fi 6	802.11ax, Wi-Fi 6
MIMO	2.4GHz 2x2, 5GHz 2x2	2.4GHz 4x4, 5GHz 4x4, 6GHz 4x4	2.4GHz 2x2, 5GHz 2x2	2.4GHz 2x2, 5GHz 2x2	2.4GHz 4x4, 5GHz 4x4
2.4GHz Radio Rate	573 Mbps	1.378 Gbps	400 Mbps	573 Mbps	800 Mbps
5GHz Radio Rate	1.7 Gbps	5.76 Gbps	867 Mbps	2.4 Gbps	3.2 Gbps
6GHz Radio Rate		11.52 Gbps
Wireless Antenna Frequency Range & Gain	2.4 - 2.4835 (GHz) 3 (dBi), 5.150 - 5.850 (GHz) 3 (dBi)	2.4 - 2.483 (GHz) 4 (dBi), 5.15 - 5.725 (GHz) 6 (dBi), 5.925 - 6.425 (GHz) 6 (dBi)	2.4 - 2.4835 (GHz) 2 (dBi), 5.150 - 5.850 (GHz) 2 (dBi)	2.4 - 2.483 (GHz) 3.53 (dBi), 5.15 - 5.85 (GHz) 5.15 (dBi)	2.4 - 2.4835 (GHz) 3 (dBi), 5.150 - 5.850 (GHz) 3 (dBi)
Ethernet Ports	2 x 1 Gbps	1 x 1 Gbps, 1 x 10 Gbps	2 x 1 Gbps	1 x 1 Gbps	1 x 1 Gbps, 1 x 2.5 Gbps
SFP Ports		1 x 10G SFP+
Max Power Consumption	15.3 W	60 W	13 W	18 W	25.4 W
Max Client Capacity	512	1500	110	512	512
Recommended client capacity	100	250	40	110	120

Technical Specs / Datasheet

Technical Specs / Datasheet - Reyee Wi-Fi 6 Ceiling Access Point

Installation Guide - Reyee Wi-Fi 6 Ceiling Access Point

Specifications

Wireless Network

Standards

802.11ax, Wi-Fi 6

MIMO

2.4GHz 2x2, 5GHz 2x2

2.4GHz Radio Rate

573 Mbps

5GHz Radio Rate

1.7 Gbps

Antenna

Antenna Design

Omni

Wireless Antenna Frequency Range & Gain

2.4 - 2.4835 (GHz) 3 (dBi), 5.150 - 5.850 (GHz) 3 (dBi)

Interfaces

RJ45 Ports

(2) 1 Gbps

Management

Ethernet

Power

Power Method

AC/DC Adapter, 802.3at PoE+

Power Supply

External AC/DC Adapter, External PoE Adapter

Max Power Consumption

15.3 W

Physical Parameters

Color

White

Dimensions

194 x 194 x 35 mm

Weight

0.56 kg

Operating Temperature

0 °C to 40 °C

Environment

Indoor

Mounting Method

Wall Mount, Ceilling Mount

Package Contains

External Power Supply

Not Included
