Product name
Teltonika Angled Compact Mobile Antenna 5dBi
Warranty
?
12 months
Manufacturer part number
PR1US450
EAN
4779051840304
Teltonika Angled Compact Mobile Antenna 5dBi
Official Teltonika Distributor
Certified Teltonika Engineers
In stock
?
4.41 €
4.41 €
Official Teltonika Distributor
Certified Teltonika Engineers
Detailed description
PR1US450 is an angled compact mobile antenna that works in the frequency range 700-2700 MHz with 5 dBi gain. PR1US450 has linear polarization and input impedance 50 Ohm. The antenna is 50 mm long and is equipped with a straight SMA Male connector.
Technical Specs / Datasheet
Compatible products
Specifications
Antenna
Antenna Design
Omni
Mobile Antenna Frequency Range & Gain
0.700 - 2.700 (GHz) 5 (dBi)
Mobile Antenna Gain
5 dBi
Polarization
Linear
VSWR
< 1.8
Impedance
50 Ω
Connectors
RF Connectors
(1) SMA Male
Physical Parameters
Color
Black
Dimensions
50 x 17 x Ø10.5 mm
