4G Outdoor Adhesive LTE Antenna 2dBi IP67 SMA Male

The JCG017L is a low-profile LTE antenna designed for cellular communication across the 698–960 MHz and 1710–2690 MHz frequency ranges. Its linear polarization and 2 dBi gain support signal transmission and reception within the specified bands, while the 50-ohm impedance makes it suitable for compatible radio equipment. A VSWR below 2.0 indicates efficient radio-frequency transfer across the operating range. The slim rectangular form integrates the antenna element inside an ABS radome, creating a compact external antenna that can be mounted directly onto a suitable surface without adding a tall protruding element. This format is practical where installation space is limited.

The antenna uses a 3 m RG174 cable terminated with an SMA male connector, providing flexibility when positioning it away from the connected device. A red adhesive layer secures the housing to the installation surface, allowing straightforward fixed placement without screws or magnetic mounting. The enclosure measures approximately 115.6 × 21.7 × 5.8 mm, so it occupies little space and maintains a discreet profile after installation. It is rated for operation from -40 °C to +85 °C and relative humidity up to 95%. IP50 protection applies to the housing, while the specified vibration resistance supports use in locations exposed to mechanical movement. RoHS compliance confirms conformity with the stated environmental requirement.
