Manufacturer part number
CCR1072-1G-8S+
Warranty
?
12 months
EAN
4752224002082
MikroTik CCR1072-1G-8S+
This item has been discontinued
We recommend to use the product presented below
MikroTik CCR2216-1G-12XS-2XQ
CCR2216-1G-12XS-2XQ
Available alternatives
Detailed description
1U Rackmount, 1x Gigabit Ethernet, 8xSFP+ cages, LCD, 72 Cores x 1GHz CPU, 16GB RAM, up to 120 Million Packets per Second, 80Gbps Throughput, RouterOS L6
The new flagship router CCR1072 is powered by a Tilera 72 core CPU, each core is clocked at 1GHz, and to fully utilize this power, the CCR1072 is equipped with eight independently connected 10G SFP+ ports and single Ethernet port for management purposes.
Thanks to the unique 72 core processor and ports that are directly connected to the CPU, CCR1072 is capable of over 120 million packets per second throughput.
Features:
- 8x SFP+ ports
- 16GB ECC RAM
- Ports directly connected to CPU
- microSD and 2x M.2
- over 120 million pps packet throughput
- up to 80 Gbps throughput 72 core CPU
- 1 GHz clock per core
- State of the art TILE GX architecture
The unit comes equipped with two removable (hot plug) power supplies for redundancy, smart card slot, eight SFP+ ports and 16GB of built in ECC RAM.
The CCR1072 also has two built-in M.2 slots, microSD and 2x USB for adding storage, to use for proxy cache, user manager and other features. The M.2 slots accept 800mm Key-M x4 PCIe 2.0 modules.
Technical Specs / Datasheet
Compatible products
Specifications
Interfaces
RJ45 Ports
(1) 1 Gbps
SFP Ports
(8) 10G SFP+
USB Ports
(1) USB-A 2.0, (1) Micro USB
Communication Interface
RJ45
Management
Ethernet
Memory card slots
1 microSD
System Specification
Chipset
TLR4-07280, 72 core, 1 GHz
RAM
16 GB
Storage Memory
128 MB
Power
Power Supply
Internal x2 redundant PSU
Supported Input Voltage
110 - 220 V AC
Max Power Consumption
100 W
Physical Parameters
Number of Rack Units
1U
Dimensions
443 x 315 x 44 mm
Operating Temperature
-20 °C to 60 °C
Mounting Method
RackMount
Form Factor
Rack-mounted 19"
Software
MikroTik
RouterOS Level 6
