LTE/GPS/GLONASS Combo Outdoor Antenna 4 dBi, 4x4 MIMO, IP67, SMA

The JCB605LM4 is a combined outdoor antenna that brings four 4G elements together with one GPS/GLONASS element in a single housing. Its 4×4 MIMO configuration is intended for compatible cellular equipment that uses four separate 4G antenna connections, while the dedicated GNSS path supports GPS at 1575.42 MHz and GLONASS across 1598–1606 MHz. The 4G elements cover 698–960 MHz and 1710–2690 MHz, providing operation across both lower and higher cellular bands. Each path has 50-ohm impedance, with linear polarization for 4G and right-hand circular polarization for GPS/GLONASS. A gain of 4 dBi defines the antenna’s stated signal characteristics without requiring multiple separate housings on the installation surface.

Five RG174 cables, each 1.5 metres long, provide individual connections for the four cellular channels and the GNSS channel. The antenna is terminated with four SMA connectors for 4G and one SMA connector for GPS/GLONASS, making the cable layout clear during installation and connection to supported routers or tracking equipment. Screw mounting secures the antenna firmly to the selected surface, while its IP67 protection rating supports outdoor use where resistance to dust and water is required. The specified operating range from -40°C to +85°C allows deployment in locations exposed to wide temperature variation. Intended applications include M2M systems, fleet management, vehicle or asset tracking, and multi-WAN routers, where one combined antenna can provide both cellular connectivity and satellite positioning through separate interfaces.
