Brand
Manufacturer part number
AWUS036AC
Warranty
?
12 months
EAN
4718050302734
Alfa USB Adapter AWUS036AC
out of stock
?
27.93 €
27.93 €
Detailed description
High-Demand Online Activities
The Alfa AWUS036AC USB WiFi adapter integrates the 802.11ac technology, supporting both 2.4 GHz and 5 GHz wireless frequencies. This device is engineered to provide high-speed internet connectivity, with maximum data rates of 300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band. Such speeds make the AWUS036AC well-suited for high-demand online activities like HD video streaming, online gaming, and extensive file transfers across multiple devices.
Powered by the Realtek RTL8812AU chipset, the AWUS036AC adheres to various WiFi standards, including 802.11ac, a, b, g, and n, ensuring broad compatibility with different network types. This adapter is notable for its enhanced signal range and penetration, attributed to two external high-gain antennas (each offering 5 dBi gain), which are pivotal in boosting WiFi coverage and improving connectivity in areas with potential signal interference or obstacles.
Reliable Connectivity for Diverse User Needs
Connectivity is facilitated through a USB 3.0 interface, promoting fast and efficient data exchange between the adapter and the computer, minimizing latency, and maintaining stable connections. The adapter is also designed for secure wireless communication, supporting encryption methods like 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, and WPS.
Operating system compatibility spans across various versions of Windows (XP to 10), macOS (10.5 to 10.14), and Linux, ensuring the AWUS036AC can serve a wide user base. Additionally, LED indicators on the device provide status updates, with different blinking patterns for driver application and active WiFi network association. This feature aids in troubleshooting and monitoring the device’s operational status.
Technical Specs / Datasheet
Compatible products
Specifications
Wireless Network
Standards
802.11a/b/g/n/ac
MIMO
5GHz 2x2
2.4GHz Radio Rate
300 Mbps
5GHz Radio Rate
867 Mbps
Antenna
Antenna Design
Omni
Wireless Antenna Frequency Range & Gain
2.412 - 2.483 (GHz) 5 (dBi), 5.1 - 5.9 (GHz) 5 (dBi)
Beamwidth
360 °
Connectors
RF Connectors
(2) RP-SMA Female
Interfaces
USB Ports
(1) USB-A 3.0
System Specification
Chipset
RTL8812AU
Physical Parameters
Color
Black
Material
Plastic
Dimensions
85 x 26 x 12 mm
Weight
0.025 kg
Environment
Indoor
