Product name
Teltonika FMM130
Warranty
?
12 months
Manufacturer part number
FMM130LNU801
EAN
4779027312576
Teltonika FMM130 GPS Tracker with LTE CAT-M1/NB-IoT, GNSS and Backup Battery
Official Teltonika Distributor
Certified Teltonika Engineers
- Real-time GPS tracker with GNSS and LTE CAT-M1/NB-IoT connectivity plus 2G fallback for reliable vehicle location monitoring worldwide.
- Built-in Bluetooth, internal GNSS and LTE antennas, and backup battery help support stable tracking in demanding fleet, taxi, rental and logistics use.
- Flexible I/O design with configurable digital, analogue and digital outputs, negative input and impulse inputs for custom tracking and control setups.
- Worldwide version supports GSM B2/B3/B5/B8 and LTE-FDD B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B28; check bands before ordering.
- Compact professional tracking terminal for cars, public transport and remote assets where accurate location acquisition and real-time visibility matter.
Official Teltonika Distributor
Certified Teltonika Engineers
57.86 €
In stock
?
57.86 €
In stock
?
Official Teltonika Distributor
Certified Teltonika Engineers
Detailed description
Small and professional real-time tracking terminal with GNSS and LTE CAT-M1/NB-IoT/GSM connectivity and backup battery. Device equipped with GNSS/Bluetooth and LTE CAT-M1/NB-IoT modules with fallback to 2G network, internal GNSS and LTE antennas, configurable digital, analogue inputs and digital outputs, negative input, impulse inputs. It is perfectly suitable for applications where location acquirement of remote objects is needed: fleet management, car rental companies, taxi companies, public transport, logistics companies, personal cars and so on.
Worldwide version. 2G (GSM): B2, B3, B5, B8; 4G (LTE-TDD): B39 (for CAT-M1 only); 4G (LTE-FDD): B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B28. Please check the bands list before order!
Configure this Teltonika GPS tracking device to work with Floomli GPS tracking Platform which have been tested of many satisfied customers. Floomli GPS is a complete location monitoring solution across the World for your objects. Choose PrePaid Floomli subscription code and decide yourself for which period of time to activate the service.Technical Specs / Datasheet
Compatible products
Specifications
Interfaces
Interface
(3) Digital Input, (3) Digital Output, (2) Analog Input, (1) Negative Input, (1) Impulse Input
Communication Interface
1-Wire, CAN adapters support
Management
Bluetooth
Tracking
OBDII Data
Supported via Bluetooth OBDII dongle
Software
Eco driving, Fuel monitoring digital, Crash detection, Towing detection
Cables
12-pin power cable for cigarette lighter socket
Sensors
BLE Sensors/ Beacons, Bluetooth temperature and humidity sensor, 1-wire TTJ temperature sensor
CAN Adapters
LV-CAN200, LV-CAN200 + DTC, ALL-CAN300, CAN-CONTROL
Authorized Driving
Magnetic iButton key, iButton reader, RFID card, 1-wire RFID reader
Power
Supported Input Voltage
10 - 30 V DC
Battery Type
Li-Ion
Battery
170 mAh 3.7 V
Internal Battery Energy
0.63 Wh
Physical Parameters
Ingress Protection Code
IP41
