Hikvision DS-1280ZJ-XS Junction Box for Dome & Bullet Cameras

The Hikvision DS-1280ZJ-XS is a junction box designed for use with dome and bullet cameras. Made from aluminum alloy with a surface spray treatment, it provides a dedicated mounting base for compatible camera installations while maintaining Hikvision’s white finish. A cable hole is integrated into the bracket, allowing camera cabling to pass through the mounting assembly as part of the installation. With overall dimensions of Φ 100 × 43.2 × 129 mm, the junction box should be installed on a flat wall, making the mounting surface an important consideration when planning its placement.

For outdoor installations, waterproof rubber is required as part of the mounting arrangement. The supporting wall must also be capable of carrying more than three times the combined weight of the camera and mount, ensuring that the installation surface meets the stated structural requirement. The DS-1280ZJ-XS has a maximum load capacity of 4.5 kg, which should be considered when selecting the camera and preparing the mounting point. Together, these installation requirements make correct wall preparation, load assessment, and outdoor sealing important parts of deploying the junction box with a dome or bullet camera.
