Brand
Ubiquiti
Manufacturer part number
UVC-G4-PTZ
Warranty?
?
12 months
EAN
0817882029353
Sensor | |||||
Sony 4K (8 MP) 1/1.8" CMOS Sensor | 5 MP CMOS Senso | 5 MP CMOS Senso | 5 MP CMOS Senso | 1/2" 8MP sensor | |
Lens | |||||
22x Optical Zoom | Fixed Focal Length | Fixed Focal Length | Fixed focal 2.8 mm | Motorized focal 4.24-12.66 mm | |
Viewing Angle | |||||
64 ° (H) 37 ° (V) | 80 ° (H) 60 ° (V) | 102 ° (H) 71 ° (V) | 102.4 ° (H) 54.9 ° (V) | 110 ° (H) 60 ° (V) | |
Resolution | |||||
3840 х 2160 | 2688 x 1512 | 2688 x 1512 | 2688 x 1512 | 3840 х 2160 | |
Maximum Frame Rate | |||||
24 FPS | 24 FPS | 24 FPS | 30 FPS | 50 FPS | |
Ethernet Ports | |||||
1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | ||
Chipset | |||||
Ambarella S5L66 | Ambarella Advanced Image Processing SoC | Quad-core Arm ® Cortex ® -A53 based chip | Dual core Arm ® Cortex ® -A7 based chip | ||
RAM | |||||
1 GB | 512 MB | 512 MB | 2 GB | ||
Storage Memory | |||||
256 MB | 256 MB | 256 MB | 2 GB | ||
Max Power Consumption | |||||
42.9 W | 4 W | 5 W | 6 W | 12.5 W | |
Operating Temperature | |||||
-40 °C to 50 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 50 °C | |
Environment | |||||
Outdoor | Indoor, Outdoor | Indoor | Outdoor | Indoor, Outdoor |
Sensor | Sony 4K (8 MP) 1/1.8" CMOS Sensor | 5 MP CMOS Senso | 5 MP CMOS Senso | 5 MP CMOS Senso | 1/2" 8MP sensor |
Lens | 22x Optical Zoom | Fixed Focal Length | Fixed Focal Length | Fixed focal 2.8 mm | Motorized focal 4.24-12.66 mm |
Viewing Angle | 64 ° (H) 37 ° (V) | 80 ° (H) 60 ° (V) | 102 ° (H) 71 ° (V) | 102.4 ° (H) 54.9 ° (V) | 110 ° (H) 60 ° (V) |
Resolution | 3840 х 2160 | 2688 x 1512 | 2688 x 1512 | 2688 x 1512 | 3840 х 2160 |
Maximum Frame Rate | 24 FPS | 24 FPS | 24 FPS | 30 FPS | 50 FPS |
Ethernet Ports | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | |
Chipset | Ambarella S5L66 | Ambarella Advanced Image Processing SoC | Quad-core Arm ® Cortex ® -A53 based chip | Dual core Arm ® Cortex ® -A7 based chip | |
RAM | 1 GB | 512 MB | 512 MB | 2 GB | |
Storage Memory | 256 MB | 256 MB | 256 MB | 2 GB | |
Max Power Consumption | 42.9 W | 4 W | 5 W | 6 W | 12.5 W |
Operating Temperature | -40 °C to 50 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 50 °C |
Environment | Outdoor | Indoor, Outdoor | Indoor | Outdoor | Indoor, Outdoor |
