Brand
Manufacturer part number
UVC-AI-Theta-Pro
Warranty
?
12 months
EAN
0810084692646
Sensor | |||||||
1/1.8" 8MP sensor | 5 MP CMOS Sensor | 5 MP CMOS Sensor | 4/3" 10MP CMOS sensor | 1/1.8" 8MP sensor | 8 MP CMOS Sensor, 360°-12 MP CMOS Sensor | 4/3" 10MP CMOS sensor | |
Lens | |||||||
Fixed Focal Length | Fisheye lens | Fixed Focal Length | M. Zuiko Digital ED 45 mm f/1.2 PRO | F 4.1 - 12.3 mm; f/1.53 – f/3.3 | Fixed Focal Length | M. Zuiko Digital ED 17 mm f/1.2 PRO | |
Viewing Angle | |||||||
180 ° (H) 180 ° (V) | 360 ° (H) 360 ° (V) | 84.7 ° (H) 46.2 ° (V) | 21.6 ° (H) 16.2 ° (V) | 109.9 ° (H) 59.9 ° (V) | 97.5°(H), 79.4°(V), 360°- 180°(H), 180°(V) | 52 ° (H) 39 ° (V) | |
Resolution | |||||||
2160 x 2160 | 1920 x 1920 | 2688 x 1512 | 3840 х 2160 | 3840 х 2160 | 2560 x 2560, 360°-3264 x 2448 | 3840 х 2160 | |
Maximum Frame Rate | |||||||
24 FPS | 30 FPS | 30 FPS | 30 FPS | 30 FPS | 24 FPS, 360°- 20 FPS | 30 FPS | |
Ethernet Ports | |||||||
1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | |
Chipset | |||||||
Quad-core Arm® Cortex®-A53 based chip | ARM® quad-core Cortex™-A53 | Quad core Arm ® Cortex ® -A53 based chip | ARM® quad-core Cortex™-A53 | Quad-core Arm® Cortex®-A53 based chip | Quad-core Arm® Cortex®-A53 based chip | Quad-core Arm® Cortex®-A53 | |
RAM | |||||||
2 GB | 2 GB | 2 GB | |||||
Storage Memory | |||||||
8 GB | 8 GB | 8 GB | |||||
Max Power Consumption | |||||||
12.5 W | 8.64 W | 7.68 W | 17.77 W | 11 W | 12.5 W | 17.77 W | |
Operating Temperature | |||||||
-20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 50 °C | -20 °C to 40 °C | -20 °C to 40 °C | |
Environment | |||||||
Indoor | Indoor, Outdoor | Indoor, Outdoor | Indoor, Outdoor | Indoor, Outdoor | Indoor | Indoor, Outdoor |
Sensor | 1/1.8" 8MP sensor | 5 MP CMOS Sensor | 5 MP CMOS Sensor | 4/3" 10MP CMOS sensor | 1/1.8" 8MP sensor | 8 MP CMOS Sensor, 360°-12 MP CMOS Sensor | 4/3" 10MP CMOS sensor |
Lens | Fixed Focal Length | Fisheye lens | Fixed Focal Length | M. Zuiko Digital ED 45 mm f/1.2 PRO | F 4.1 - 12.3 mm; f/1.53 – f/3.3 | Fixed Focal Length | M. Zuiko Digital ED 17 mm f/1.2 PRO |
Viewing Angle | 180 ° (H) 180 ° (V) | 360 ° (H) 360 ° (V) | 84.7 ° (H) 46.2 ° (V) | 21.6 ° (H) 16.2 ° (V) | 109.9 ° (H) 59.9 ° (V) | 97.5°(H), 79.4°(V), 360°- 180°(H), 180°(V) | 52 ° (H) 39 ° (V) |
Resolution | 2160 x 2160 | 1920 x 1920 | 2688 x 1512 | 3840 х 2160 | 3840 х 2160 | 2560 x 2560, 360°-3264 x 2448 | 3840 х 2160 |
Maximum Frame Rate | 24 FPS | 30 FPS | 30 FPS | 30 FPS | 30 FPS | 24 FPS, 360°- 20 FPS | 30 FPS |
Ethernet Ports | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps | 1 x 1 Gbps |
Chipset | Quad-core Arm® Cortex®-A53 based chip | ARM® quad-core Cortex™-A53 | Quad core Arm ® Cortex ® -A53 based chip | ARM® quad-core Cortex™-A53 | Quad-core Arm® Cortex®-A53 based chip | Quad-core Arm® Cortex®-A53 based chip | Quad-core Arm® Cortex®-A53 |
RAM | 2 GB | 2 GB | 2 GB | ||||
Storage Memory | 8 GB | 8 GB | 8 GB | ||||
Max Power Consumption | 12.5 W | 8.64 W | 7.68 W | 17.77 W | 11 W | 12.5 W | 17.77 W |
Operating Temperature | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 40 °C | -20 °C to 50 °C | -20 °C to 40 °C | -20 °C to 40 °C |
Environment | Indoor | Indoor, Outdoor | Indoor, Outdoor | Indoor, Outdoor | Indoor, Outdoor | Indoor | Indoor, Outdoor |
